| ORIGIN OF PLACE: | Guangdong, China | GRADE: | 6000. 7000 |
|---|---|---|---|
| FINISH: | Anodized | ALLOY OR NOT: | Is Alloy |
| SIZE: | Customized | COLOR: | Deep Bronze |
| KEYWORD: | Roller Shutter | ||
| HIGH LIGHT: | roller shutter aluminium, aluminium roller shutters | ||
| Advantages of the extrusion process | ||
| The extrusion process provides virtually unlimited opportunities for aluminium product shapes. Costs are cut by designing fewer components, which reduce fabrication and simplify assembly. | ||
| These features and benefits are unmatched by other materials and processes | ||
| Complex integral shapes | Cost effective | Low tooling costs |
| Design flexibility | Versatility in joining | Machinable |
| Rapid prototyping | Short lead times | Wide range of finishes |
Anodized surface treatment
| Anodized surface treatment: minimum partial thickness of coating on decorative surface around 8μm – 10μm. |
Powder coating surface treatment
| Powder coating surface treatment: minimum partial thickness of coating on decorative surface≥40μm;Maximum partial thickness≤120μm. |
Electrophoretic coating surface treatment
|
Class |
Film thickness um | ||
| Local thickness of anodize oxide film um | paint film local film thickness um | complex film local film thickness um | |
| A | ≥9 | ≥912 | ≥21 |
| B | ≥9 | ≥7 | ≥16 |
| Note: Electrophoretic paint profiles are supplied at B level, and other grades can be supplied as required by customers. | |||
1. Brand name: Kaiyamei Aluminum
2. Material: 6063
3. Temper: T3-T8
4. Thickness: General profile 0.8mm – 5.0 mm
5. Color: Bronze, silver, Gold, Black, Champagne or as your request
6. Surface Treatment: Anodize, Powder coating, Wooden grain, elecrophoresis, PVDF coating and so on,
7. Certification: ISO 9000 ; ISO 9001 ; ISO 14000 ; CQC ; RoHS
8. Shape: Square , flat , round , hollow , oval , triangle , U – profiles , L – profiles , T – profiles, H – profiles , customized avaliable9. Deep Processing: Cutting , punching , drilling , tapping , milling , bending , welding etc.10. Manufacture Technological Process: Aluminum ingot → Melting and casting → Homogenizing → Extrusion → Aging → Powder coating → Pouring rubber for heat insulation → Acceptance test → Packing → Warehouse → Delivery
11. Markets: Australia , Germany , North America , Africa and European countries and area
