Bluesun Perc Overlap Solar Cell Mono Crystalline Solar Panel High Efficiency 340w 350watt 360wp

Electrical Characteristics

Model Number

BSM340M-60OPH

BSM345M-60OPH

BSM350M-60OPH

BSM355M-60OPH

BSM360M-60OPH

Testing Condition

STC

Maximum Power (Pmax/W)

340

345

350

355

360

Open Circuit Voltage (Voc/V)

38.1

383

38.5

38.7

38.9

Short Circuit Current (Isc/A)

11.62

11.72

11.81

11.91

11.99

Voltage at Maximum Power (Vmp/V)

31.4

31.6

31.8

32.0

32.2

Current at Maximum Power (Imp/A)

10.83

10.92

11.01

11.10

11.18

Module Efficiency(%)

19.4

19.7

20.0

20.3

20.6

STC (Standard Testing Conditions): Irradiance 1000W/m2, Cell Temperature 25℃, Spectra at AM1.5
