| Par NO.
Parameter |
LY-EPL10060XX | |||||
| Light output | 60W | |||||
| Input Power | AC100-240V 50/60Hz | |||||
| Luminous flux(lm) | 7000-9000 | |||||
| LED Quantity(pcs) | 252PCS | |||||
| Chip Brand | Samsung / SMD 2835（0.5W） | |||||
| Color Temperature | Pure white:5000-6500K | Warm white:4000-4500K | Neutral white:2700-3200K | |||
| CRI | ＞80 | |||||
| Cover | clear glass | clear glass
+ wire guard |
clear striped spherical glass | clear striped spherical glass + wire guard |
||
| Luminous efficiency(lm/w) | 135-150 LM/W | 130-145 LM/W | 125-140 LM/W | 115-130 LM/W | ||
| Viewing Angle | 110° | 110° | 120° | 120° | ||
| Material | Die Casting Aluminum | |||||
| Lifespan(h) | ＞50000 | |||||
| IP Rating | IP66 | |||||
| Explosion-proof Mark |
 II 2G Ex db IIC T6 Gb |
|||||
| Safety Certification | ATEX | |||||
| Warranty Time | 5 Years | |||||
Mainly suitable for
1. Warehouse, factory and workshops;
2. Petroleum and petrochemical area, and gas station;
3. Power, railway, ship port, public security, fire protection and other fields.
1>when installing the conduit, remove the compression nut on the screw thread of the lamp. Requirement of waterproof for fixture connection and requirement of conduit system connection should according to the local regulations.
2> Please turn off power before install or change assembly parts.
3> The input voltage and lamps should be matched, after connecting the power line,
Please make sure the wiring section is insulated.
4> No-professionals, must not install and disassemble the lamps.
