LINSN TS802 LED Display Controller Sending Card

Specification

• Linsn TS802 LED Display Controller , LINSN TS802 LED Sending Card
• Linsn control card

  Led display control card

  Send card

• . 802 sending card including full-color sending card TS802 and dual-color sending card DS802.
  Full-color sending card supports full-color, dual-color and single color led display
  Dual-color sending card supports dual-color and single color led display.
  2. 802 sending card max supports 2048*640
  3. Supporting display mode: 640*480  800*600  1024*768  1280*768  1280*800 1280*1024
  1440*900  1440*1080  1600*1200
  1680*1050  1728*1296  1920*1080  1920*1200  2048*1152  2048*1280
  4. Audio Transmission Function802 sending card sends audio data using network cable, and Function
  board outputs audio signals to the display. Double 24bits 64KHZ hifi digital signal to analog signal
  or analog signal to digital signal, making display have the perfect video effect.
  5. Cascade functionThrough the dig switch on 802 sending card, several 802 sending cards can be
  easily cascaded to support a super large led display
  6. Sending card U/D port flexibility for carrying half width or half heightFor example, TS801 can max
  support 1280*1024 with two portsA single network output port supports 1280*512 or 640*1024
  7. Sending card rotation functionIn Sender setting, sending card has 0, 90, 180, 270 degree rotation function
  8. Sending card zoom in/out functionIn Sender setting, the ratio of width and height can be set to
  realize zoom in or zoom out
  9. Supporting 10-bit colors The seventh supports 8-bit colors: 256*256*256=16777216 kinds of colors.

• Cerfication
• CCC:2014010903669954

  CE:14AE06060E 001

  ROHS:16AC05068R 001

  CE:14AS06060L 950A
