| Name | 43″ J Type Curved Closed Frame Touch Monitor with Front Facing LED Light |
| Model | K43CTMCFJL |
| LCD Panel Parameters | |
| Display Technology | Active Matrix TFT-LCD With LED Backlight |
| Aspect Ratio | 16:09 |
| Active Area (W x H) | 941.18×529.42mm |
| Native Resolution | 3840×2160@60Hz |
| Response Time (Typ.) | 8ms |
| Display Colors | 1.07B |
| Luminance (Typ.) | 450nits; with P-Cap 405nits |
| Contrast Ratio (Typ.) | 4000:01:00 |
| Viewing Angle (Typ.) | Horizontal (left/right) CR≥10 89°/89° ; Vertical (up/down) CR≥10 89°/89 |
| Touch Screen Parameters | |
| Touch Technology | Projected Capacitive (P-Cap) |
| Surface Treatment | Tempered or Chemically Strengthened;Optional: Anti-Glare, Antimicrobial |
| Active Area | 941.18×529.42±0.5mm |
| Thickness(Total) | 4.65±0.3mm |
| Light Transmission | ≥83% |
| Response Time | 8ms |
| Touch Screen Interface | USB |
| Touch Point | 10 |
| Overall Parameters | |
| Case/Bezel Color | Black |
| Radius | R1500 |
| Mounting Options | VESA: 600×300 mm |
| Outline Dimensions（W×H×D） | 1026.18mm × 625.60mm× 157.29mm |
| Power Supply | Input Voltage Range: +24VDC ± 5% |
| On Screen Display (OSD) | Control (back): Power, Auto, Up, Down, Menu |
| Power Consumption | MAX: 120W |
| Operating Altitude | ≦3000m |
| Temperature Range | Operating: 0℃ to 40℃, storage: -20℃ to 60℃ |
| Humidity (Non Condensing) | Operating: 20% to 80%, storage: 10% to 90% |
| I/O | HDMI, DVI, DP, USB |
| Accessories | Cables: HDMI×1, USB×1 |
| Carton Box Dimensions(1 units in one carton) | 1145mm (L) × 240mm (W) × 785mm (H) |
| Weight | Gross: 24kg; Net: 30kg |
| MTBF | 50,000 hours demonstrated |
| LED Lights Color | Multicolor |
| LED Lights Location | 4 LED lights bar (Front, Edge & Back ) |
| Agency Approvals | CE , FCC |
| Warranty | 2 years |
