constant current adjustable LED edgelit-light with aluminum frame SMD3535 36V
SMD3535 high power LED edge-lit solution, Samsung chip, special design of LENs to allow narrow beam angle 15*45. It is used for single or double sided lightboxes. 36VDC input. The bijective distance can be up to 1800mm for fabric light box. Aluminum PCB for good heat dissipation. For indoor fabric light box. We could provide power supply 18 led with one power supply 36V.
Product parameters
| Model | LED module 3535 |  |
| Led source | Edge-light | |
| Type | Rigid strip | |
| Body Material | aluminum frame | |
| Function | for light box, Lighting | |
| Color temperature | 7000K-8000K | |
| Emitting color | RGB/ white | led can be waterproof Mould for constant current high power led |
| Light Angle | 15*45 |  |
| Length | 45CM, 5 lamp beads | |
| Lamp power | 11.5W/meter | |
| CRI(Ra>) | 80 | |
| Input voltage | DC36V | |
| Lamp luminous flu(lm) | 400 | |
| Working lifetime(hour) | 50000-70000 | |
| IP rating | IP34 | |
| Working temperature | -40-60 | High quality aluminum alloy base. Excellent heat exchange |
| Led chip brand | Samsung |  |
| OEM & ODM | Both | |
| Certification | UL,CE,ROHS | |
| Free Sample | one sample is available | |
| MOQ | 1pcs | |
| Packaging details | carton+splint wooden frame | |
| EXW price | USD2.13 /per led | |
| Supply ability | 100000 meters/ per week | With constant current power supply |
