HD 4K Small Pixel Ndoor Led Display Screen , High Brightness Led Display Nation Star
| Place of Origin | China |
| Brand Name | TBC |
| Certification | CE-EMC, CE-LVD, RoHS, ETL, FCC |
| Model Number | Mi125 |
Product Details
HD 4K Small Pixel Indoor Led Display High Definition 3840Hz Refresh Rate Light Weight Design
Lightweight slim design, easy front installation and service, high contrast ratio, noiseless design, ultra wide viewing angle, making 4K Video Quality P1.5mm Indoor High Refresh 3840Hz Video Screen with No Moire Effect High Precision Cabinet perfect choice for premium setup for 5 star hotels, traffic center, schools, stage, public security, shopping centers and other fields.
Seamless Design Cabinet
Molding cabinet cabinet, high precision, easy seamless splicing
Dual Back Up of Power and Signal
Stable and reliable operation, supporting 7×24 hours non stop working
Cabinet ratio 16:9, is a golden ratio for ultimate visual experience;
CNC High Quality Die Cast Aluminum Cabinet
Die casting aluminum cabinet with perfect CNC finishing, high precision in structural dimensions with less than 0.1mm tolerance
Slim and Thin Design
Single cabinet weight only 8kg; adopting stylish cabinet frame design, only 73mm the whole cabinet
Friendly User Experience
Front magnetic service, easy to use and maintenance
| Brightness | nits | 600 | ||
| Color temperature | deg.k | 3200 ~ 9300 | ||
| Viewing angle – Horizontal | deg. | 160(+80/-80) | ||
| Viewing angle – Vertical | deg. | 160(+80/-80) | ||
| Cabinet weight | kg | 7 | ||
| Cabinet width | mm | 400 | ||
| Cabinet height | mm | 300 | ||
| Cabinet depth | mm | 80 | ||
| Cabinet area | sq. m. | 0.23 | ||
| Cabinet material | Aluminum | |||
| Aspect ratio | 16:9 | |||
| Ingress protection (Front/Rear) | IP | IP40/IP20 | ||
| Operating temperature range | deg. C | 0 to 40 | ||
| Operating humidity range | HR | 10％ to 90％ | ||
| Pixel type and configuration | R/G/B | SMD 3in1 | ||
| Pixel pitch | mm | 1.25 | ||
| Pixel matrix per cabinet | 480×270 | |||
| Pixels per cabinet | 129600 | |||
| Lines per meter | 750 | |||
| Pixels per sq. meter | 562781 | |||
| LEDs per sq. meter | 562781 | |||
| Recommended minimum viewing distance | m | 1 | ||
| Colours | 281trillion | |||
| Gray scale | Levels | 65536 levels per colour | ||
| Brightness control | Levels | 100 | ||
| Digital processing | bit | 16 | ||
| Frame rate | Hertz | 60 | ||
| Display refresh rate | Hertz | 3840 | ||
| Input voltage | VAC | 110/240 | ||
| Input power frequency | Hertz | 50/60 | ||
| Input power (max/avg) | Watts per sq.m | 800/280 | ||
| MTBF | Hours | ≥10000 | ||
| Lifetime (50%Brightness) | Hours | ≥100000 | ||
| Module brightness uniformity | ＜5％ | |||
| Blind spot rate | ＜0.0001 | |||
| Earth leakage current | mA | ＜2 | ||
| Red wavelength | nm | 623 | ||
| Green wavelength | nm | 525 | ||
| Blue wavelength | nm | 470 | ||
| Panel input format (with video processor) | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV | |||
| Data interconnection | CAT6 cable/Fiber | |||
| Operating system | Windows(XP/Vista/7/8/10) | |||
| Control distance | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. | |||
